| Camera |
| Image Sensor2 MP CMOS |
| Signal System PAL/NTSC |
| Max. Resolution1920 (H) × 1080 (V) |
| Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Day & Night IR Cut Filter |
| Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Lens |
| Lens Type2.8 mm, 3.6 mm Fixed Lens |
| Focal Length & FOV |
| 2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5° |
| 3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0° |
| Lens MountM12 |
| Illuminator |
| Supplement Light Range Up to 20 m |
| Image |
| Frame Rate |
| TVI: 1080p@25fps/30fps |
| AHD: 1080p@25fps/30fps |
| CVI: 1080p@25fps/30fps |
| CVBS: PAL/NTSC |
| Wide Dynamic Range (WDR)Digital WDR |
| Image Parameters Switch STD/HIGH-SAT |
| Day/Night Mode Auto/Color/BW (Black and White) |
| White Balance Auto |
| Image Enhancement DWDR, BLC, Global |
| Noise Reduction2D DNR |
| Image Settings Brightness, Mirror, Smart IR, Sharpness, AGC |
| Interface |
| Video Output Switchable TVI/AHD/CVI/CVBS |
| General |
| Language English |
| Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Material Plastic |
| Communication HIKVISION-C |
| DimensionΦ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″) |
| Weight Approx. 195g (0.43 lb.) |
| Power12 VDC ± 25%, Max. 3.3 W |
