| Camera | |
| Image Sensor | 1/2.8″ CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM | 16 MB |
| RAM | 64 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.005 lux@F1.6 (Color, 30 IRE); |
| 0.0005 lux@F1.6 (B/W, 30 IRE); | |
| 0 lux (Illuminator on) | |
| S/N Ratio | ＞ 56 dB |
| Illumination Distance | Up to 30 m (98.43 ft) (IR); |
| Up to 15 m (49.21 ft) (Warm light) | |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 2 (Multi-core (IR + warm) light) |
| Angle Adjustment | Pan: 0°–360° |
| Tilt: 0°–90° | |
| Rotation: 0°–360° | |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F1.6 |
| Field of View | 2.8 mm: H: 105°; V: 56°; D: 126° |
| 3.6 mm: H: 87°; V: 44°; D: 105° | |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 0.7 m (2.30 ft) |
| 3.6 mm: 1.3 m (4.27 ft) | |
