General |
|
| Interfaces | • 24 x 10/100/1000 Mbps PoE |
| • 2 x Gigabit SFP | |
| • 2 x 10G SFP+ | |
| Port Standards & Functions | • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3 10BASE-T Ethernet |
| • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • IEEE 802.3ae 10 Gigabit Ethernet | |
| • IEEE 802.3x Flow Control for full-duplex mode, auto-negotiation | |
| Network Cables | • UTP Cat. 5, Cat. 5e (100 m max.) • EIA/TIA-568 100-ohm STP (100 m max.) |
| Duplex Mode | • Full/half-duplex for 10/100 Mbps and full-duplex for 1000 Mbps speed |
| Media Interface Exchange | • Auto or configurable MDI/MDIX |
Performance |
|
| Switching Capacity | • 92 Gbps |
| Transmission Method | • Store-and-forward |
| MAC Address Table | • Up to 16,384 entries per device |
| MAC Address Update | • Up to 512 static MAC entries • Enable/disable auto-learning of MAC addresses |
| Maximum Packet Forwarding Rate | • 68.45 Mpps |
| Packet Buffer Memory | • 1.5 MB per device |
| MTBF | • 275,428 hours |
| Flash Memory | • 32 MB |
| DRAM Size | • 256 MB |
PoE |
|
| PoE Standard | • IEEE 802.3af/at |
| PoE Capable Ports | • Ports 1 to 24: Up to 30 W |
| PoE Power Budget | • Max. 193 W |
Physical & Environment |
|
| AC Input | • 100 to 240 VAC 50/60 Hz internal universal power supply |
| Maximum Power Consumption | • 238.7 W (PoE on) • 29 W (PoE off) |
| Standby Power Consumption | • 21 W |
| Fans | • 2 x smart fans |
| Acoustics | • 46.4 dB(A) |
| Heat Dissipation | • 813.97 BTU/hr |
| Temperature | •Operation (-5 to 50 ˚C (23 to 122 ˚F)) • Storage (-20 to 70 ˚C (-4 to 158 ˚F)) |
| Humidity | •Operation (0% to 95% non-condensing) •Storage (0% to 95% non-condensing) |
| Certifications | • CE, FCC, C-Tick, VCCI, BSMI, CCC, IPv6 Ready Logo Phase 2 |
| Safety | • cUL, CB |
