General |
|
| Size | • Desktop (with Mounting Kit) |
| Interfaces | • 8 10/100/1000 BASE-T ports • 2 GE Uplink |
| Standards | • IEEE 802.3u, FastEthernet standards • IEEE 802.3x, Full-duplex Ethernet data link layers |
| • IEEE 802.3ab, GigabitEthernet standards • IEEE 802.3az, EEE, Energy efficient Ethernet standard | |
| • IEEE 802.3z, Gigabit Ethernet fiber-optic standar •IEEE802.3af/at, Ethernetpower supplyPOE standard | |
| Media Interface Exchange | • Auto MDI/MDI-Xadjustment on all ports |
| Lighting Protection | • 6KV |
Performance |
|
| Switching Fabric | • 20 Gbps |
| Transmission Method | • Adopt Store-and-forward |
| Data Transfer Rates | •Gigabit Ethernet •Ethernet |
| •1000 Mbps •100 Mbps | |
| Packet Filtering / Forwarding Rates | •10M port maximum 14800pps |
| •100M port maximum 148800pps | |
| •1000M port maximum 1488000pps | |
PoE |
|
| PoE Standards | •IEEE 802.3af IEEE 802.3at |
| PoE-Capable Ports | •Port 1 – 8 (Port 1 – 8 PoE can support up to 250m @ 10Mbps with Extend enabled) |
| Power Budget | •120W (30 W max. per PoE port) |
LEDs |
|
| Power | •✓ |
| Link/Activity | •✓ |
Physical |
|
| Dimensions | •184mm*94mm*27mm |
| Power | •120W |
| Temperature | •Operating: 0 to 40 ˚C (32 to 104 ˚F) |
| Humidity | •Operating: 0% to 95% RH non-condensing •Storage: 0% to 95% RH non-condensing |
Certification |
|
| EMI/EMC | • CE |
