Interfaces |
|
| Ports | • 24 x SFP ports • 2 x 10GBASE-T ports • 4 x 10G SFP+ ports |
| Optional Redundant Power Supply | • DPS-500A • DPS-500DC |
| Console Port | •10/100/1000BASE-T RJ-45 port for out-of-band CLI management |
| Management Port | •10/100/1000BASE-T RJ-45 port for out-of-band IP management |
| Stacking Ports | •4 |
| Stacking Cost1 | •1 |
| USB Ports | •1 x USB 2.0 Type A port |
Physical |
|
| MTBF (Hours) | •400,490 hours |
| Acoustics | • Max: 52.3 dB • Min: 42.7 dB |
| Heat Dissipation | •221.8 BTU/h |
| Power Input | •100 to 240 VAC, 50 to 60 Hz |
| Max Power Consumption | • Max.: 65.01 W • Standby: 22.77 W |
| Emission (EMI) | •FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI |
| Safety | •CB, cUL, BSMI |
